Spindleless Vneer Peeling Machine_Shandong Menglianggu Machinery Manufacturing Co., Ltd.

Shandong Menglianggu Machinery Manufacturing Co., Ltd.

banner

Plywood Production Line

Spindleless Vneer Peeling Machine

Product Introduction

Place of Origin

Shandong, China

Condition

New

Type

Log Debarker

Weight (kG)

6500 kg

Applicable industries

Building Material Shops, Manufacturing Plant,Other, wood, woodworking machinery factory veneer peeling factory, wood-based machinery panel factory

Warranty

1 Year

Key Selling Points

High Safety Level

Usage

Wood Debarkers

Brand Name

MLG

Voltage

380V

Dimension(L*W*H)

4700*2300*1500mm

Power (kw)

11

Video outgoing-inspection

Provided

Warranty of core components

1 Year

Core Components

Bearing, Motor, Pump, Gear, PLC, Other, Gearbox

Pressure vessel, Engine, Other

After-sales Service Provided

Technical Online Service

Color

customize

Product name

MLG Veneer Peeling Machine

Keywords

Wood Log Tree Debarker Machine

Working methods

Fully Automatic

Steel material

Superior Standard

Model

MLG

Brand

MLG

Veneer thickness

0.8-3.5mm

Panel Length(mm)

60mm


Max log diameter

600mm

Min log diameter

30mm

Max log length

1300mm

Veneer thickness

0.8-4mm

Speed

57m/min (Speed can be adjusted)

Feeding

7.5KW

Cutting

4KW


Specially fitting for hard wood, more stable and more durable ,as well as the produced veneers are with higher accuracy.

The veneer peeling line not only improves the quality and precision of veneer production, but also greatly improves the production efficiency and the degree of automation of the whole machine.

The veneer peeling line is one of the main equipment for producing plywood. We can provide veneer peeling machine, Automatic Stacker machine and Wood Log Debarker and the related knife grinding machine.


Remarks:
We can produce it according to your request. Welcome drawings from you.

Spindleless Vneer Peeling Machine(图1)

Spindleless Vneer Peeling Machine(图2)

Advanced Technology

Enlarged double drum and single drum, double power improves its peeling speed, suitable for both hardwood and softwood, the drum is chrome plated for more wear resistance and durability.

Spindleless Vneer Peeling Machine(图3)

High Efficiency

Simple operation, high productivity, peeling speed up to 40-50 m / min, adjustable speed,very high efficiency.

Spindleless Vneer Peeling Machine(图4)

Servo Feeding Motor

Our feeding motor and shearing motor use servo motor of Foton. It is better than other brands of servo motors. Precise feeding will make the veneer thickness more uniform, while the shearing servo motor provides precise cutting width.

Spindleless Vneer Peeling Machine(图5)

Veneer Peeling Production Line

A complete automated veneer peeling line includes log peelers, infeed conveyors, veneer peelers and stackers.

Spindleless Vneer Peeling Machine(图6)

Spindleless Vneer Peeling Machine(图7)
